4430A Smart IP Asennuskaiutin

SPL
104 dB

Vahvistimen teho
50 W Basso (Class D) + 50 W Diskantti (Class D)

Taajuusvaste
45 Hz - 39 kHz (-6 dB)

Taajuusvasteen tarkkuus
± 1.5 dB (58 Hz - 20 kHz)

Kaiutinelementtien mitat
⌀ 130 mm Basso + ⌀ 19 mm Diskantti (muunna tuumiksi)

Mitat
H 285 x W 189 x D 178 mm, (muunna tuumiksi)

Paino
5.1 kg / 11.2 lb

Liitännät
1 x RJ45 AES67 / Dante Sisääntulo
1 x Euroblock Analoginen Sisääntulo
4430A Smart IP Installation Speaker
Tekniset tiedot
Järjestelmän tiedot
Taajuusvaste
58 Hz - 20 kHz (± 1.5 dB)
Alarajataajuus -6 dB
45 Hz
Ylärajataajuus -6 dB
39 kHz
SPL
Maksimiäänenpaine Maksimiäänenpaineen piikki, kaiutinpari mitattuna musiikkimateriaalilla 1 metrin etäisyydeltä.
≥107 dB
Hetkellinen maksimiäänenpaine Lyhyen ajan maksimiäänenpaine siniaallolla puoliavaruudessa, keskiarvo 100 Hz - 3 kHz, 1 metrin etäisyydeltä.
≥104 dB
Pitkäkestoinen maksimiäänenpaine Pitkän ajan RMS-maksimiäänenpaine samoissa olosuhteissa IEC-painotetulla melulla 1 metrin etäisyydeltä (kaiuttimien suojapiirien rajoittama).
≥96 dB
Akustinen pohjakohinataso
Akustinen pohjakohinataso Kaiuttimen oma melutaso 1 metrin etäisyydeltä vapaakentässä (A-painotettu).
≤5 dB
Paino
Paino5.1 kg (11.2 lb)
Mitat
Korkeus
285 mm
Leveys
189 mm
Syvyys
178 mm

Kotelo
Kotelomateriaali
Die cast aluminium
Kotelotyyppi
Reflex port
Kaiutinelementit
Kaiutinelementtityyppi
Cone
Halkaisija
130 mm
Kaiutinelementtityyppi
Metal dome
Halkaisija
19 mm
Suuntaavuus


Harmoninen särö
> 100 Hz ≤0.5 %
Ryhmäviive
Viivästys äänen syntymiseen, mitattuna analogiasignaalitulosta korkeilla taajuuksilla:
2.3 ms (analogiatulo)
Genelec ilmoittaa kaiuttimen suorituskykytiedoissa ajan, joka kuluu äänen muodostumiseen siitä, kun sähköinen signaali on saapunut kaiuttimen tuloliittimeen. Tämä aika ilmoitetaan latenssina ja ryhmäviivekäyrän antamana viiveenä ja kaiuttimen aiheuttama kokonaisviive on näiden kahden summa. Jotta saa käsityksen tämän kokonaisviiveen merkittävyydestä, on hyvä tietää, että kaiuttimen siirtäminen 1 m kauemman tuottaa noin 3 ms lisäviiveen.

Vahvistimet
Vahvistimet
50 W Class D
50 W Class D
Käyttöjännite
PoE+/PoE
Tehonkulutus
ISS-valmiustilassa
≤4 W
Ilman kuormaa
≤5 W
Täysi kuormitus
25.5 W
Jakosuodin
Liitännät
Sisääntulo RJ45-liittimet
Sisääntulo Audio input is via a 10 kOhm balanced connector.
Jakotaajuus
Bass/Treble
2900 Hz
Tarkempia lisätietoja lisäksi tuoteoppaissa.

Tehoa kaiuttimelle
4430 yhdistää luokkansa parhaan äänenlaadun ja yhden kytkentäkaapelin helppouden, käyttäen PoE-teknologiaa tinkimättömän äänenlaadun ja akustisen suorituskyvyn tuottamiseksi. Se on täysin yhteensopiva Danten ja avointen standardien kuten AES67 ja ST2110-30 kanssa. Smart IP kaiuttimet on valmistettu Suomessa kestävän kehityksen periaatteiden mukaisesti ja suunniteltu palvelemaan vuosikymmeniä.

Tehoa asennukseen
Osana Smart IP tuoteperhettä 4430 integroituu saumattomasti Smart IP ohjemistoon. Se mahdollistaa asennuskonfiguraatiossa lähes rajattoman määrän huoneita, alueita, kaiuttimia ja audiokanavia sisältäen toiminnallisuuden kaiuttimien tunnistukseen, joustaviin huonekorjauksiin, järjestelmän organisointiin ja tilaseurantaan. Julkinen API-rajapinta sallii järjestelmän kaiuttimien yhdistämisen taloautomaatiojärjestelmiin päivittäiskäyttöä varten.
Avainteknologiat

Active Crossovers

Directivity Control Waveguide (DCW™)

Intelligent Signal Sensing (ISS™)

Minimum Diffraction Enclosure (MDE™)

Optimized Amplifiers

Protection Circuitry

Reflex Port Design

Versatile Mountings
Aktiivisessa jakosuotimessa käsitellään linjatasoista signaalia.
Aktiiviset jakosuotimet jakavat audiosignaalin taajuuskaistoihin, jotka ohjataan erillisiin tehovahvistimiin. Vahvistimet on kytketty kyseiselle taajuuskaistalle optimoituihin kaiutinelementteihin.
Aktiivikaiuttimissa käytetään sekä digitaalisia että analogisia jakosuotimia. Genelecin digitaalisissa aktiivijakosuotimissa on myös muita signaalinkäsittelytoiminnallisuuksia, kuten elementtien suojaus, lentoaikakompensointi ja taajuuskorjaus.
Genelecin analogisissa aktiivijakosuotimissa perustuu elektronisiin komponentteihin, jotka käsittelevät matalatasoista signaalia ennen tehovahvistusta. Aktiiviset jakosuotimet eroavat toimintaperiaatteeltaan passiivisista jakosuotimista, joissa käsitellään voimakkaita signaaleja, suurta virtaa ja toisinaan myös suurta jännitettä.
Tyypillisessä kaksitiekaiuttimessa tulosignaali jakosuodatetaan kahdelle erilliselle tehovahvistimelle, joista toinen ohjaa bassoelementtiä ja toinen diskanttielementtiä.
Aktiivisella jakosuodinteknologialla on useita etuja:
- Elementin sähködynaamiset muutokset eivät vaikuta taajuusvasteeseen.
- Signaalia voidaan säätää joustavasti käytettävän elementin ominaisuuksien mukaisesti.
- Jokaisen elementin tulosignaali prosessoidaan ja vahvistetaan yksilöllisesti. Yksittäisten elementtien signaalit eivät häiritse toisiaan, mikä vähentää keskeismodulaatiosäröä ja yliohjausongelmia.
- Elementtien välisiä herkkyyseroja voidaan kompensoida.
- Elementin ominaisuuksiin liittyviä taajuus- ja vaihevasteen poikkeamia voidaan kompensoida halutulla päästökaistalla.
- Aktiivinen jakosuodin mahdollistaa lisäksi taajuusvasteen säätämisen sekä kaiuttimen optimoinnin kaiutinjärjestelmään ja erilaisiin kuunteluympäristöihin ilman ulkoisia taajuuskorjaimia. Tuloksena on yksinkertainen, luotettava, tehokas, tarkka ja johdonmukaisesti käyttäytyvä aktiivikaiutinjärjestelmä.
Directivity Control Waveguide (DCW™) -suuntain tuottaa tasaisen taajuusvasteen laajalle kuuntelualueelle.
Vallankumouksellinen Directivity Control Waveguide™ (DCW™) -teknologia parantaa huomattavasti suoraan säteilevän monitiekaiuttimen suorituskykyä.
Tavoite on sovittaa taajuusvaste ja elementtien suuntaavuus kaiuttimessa. Lopputuloksena saavutetaan erinomainen taajuusvaste sekä kaiuttimen akustisella akselilla että sivusta mitattuna.
Parantunut kontrolloitu suuntaavuus vähentää huoneheijastumia kuuntelupaikalle. Tämä parantaa stereokuvaa ja asettaa vähemmän vaatimuksia huoneakustiikalle.
DCW-teknologia parantaa elementin herkkyyttä jopa +6 dB:ä, mikä mahdollistaa suuremman kokonaisäänenpaineen vähentäen samalla säröä ja parantaen luotettavuutta.
###DCW™-suuntaimen tärkeimmät edut:
- Tasainen taajuusvaste laajemmalle kuuntelualueelle
- Parantunut suoran äänen suhde heijastuneeseen ääneen vähentää tilan vaikutusta lopputulokseen
- Tarkempi stereokuva
- Parantunut elementtien hyötysuhde
- Järjestelmän suurempi maksimiäänenpaine
- Pienentynyt elementtien särö
- Vähemmän kaiutinkotelon reunan aiheuttamaa äänen heijastumista
- Parantunut elementtien luotettavuus, koska saman äänenpaineen tuottamiseen tarvitaan vähemmän tehoa ja pienempi kalvon liikepoikkeama
Intelligent Signal Sensing (ISS™) -valmiustilatoiminto vähentää virrankulutusta.
Genelec kehitti vuonna 2013 Intelligent Signal-Sensing -piirin, joka täyttää sekä ErP-direktiivin vaatimukset että Genelecin omat direktiiviä tiukemmat vastuullisuusvaatimukset.
ISS™-piiri seuraa kaiuttimien signaalinsyöttöä ja havaitsee, milloin signaali on käytössä. Jos ISS-piiri ei havaitse audiosignaalia hetkeen, se asettaa kaiuttimen valmiustilaan, jossa kaiuttimen virrankulutus on alle 0,5 wattia. Kun syöttösignaali havaitaan, kaiutin kytkeytyy päälle itsestään. Kaiutinjärjestelmä alkaa siis säästää sähköä heti, kun työskentely katkeaa.
Jokaisen kaiuttimen taustalevyssä on huonevasteen säätimien vieressä ISS Disable -kytkin. Kun päävirtakytkin on asennossa ON, ISS™-toiminto on oletusarvoisesti päällä.
Jos ISS-toimintoa ei haluta käyttää, se voidaan poistaa käytöstä kääntämällä ISS Disable -kytkin asentoon ON. Tällöin kaiuttimen virransyöttöä ohjataan päävirtakytkimestä.
Päävirtakytkin katkaisee kaiuttimen virransyötön kokonaan.
Minimum Diffraction Enclosure (MDE™) -kotelo tuottaa värittymättömän äänen.
Etulevyn akustisista epäjatkuvuuskohdista syntyvä diffraktio on tyypillinen vapaasti sijoiteltavan kaiuttimen ongelma. Kotelon terävät kulmat aiheuttavat heijastuksista johtuvia toisioäänilähteitä, jotka värittävät ääntä ja heikentävät äänikuvan tarkkuutta.
Parantaakseen vapaasti sijoiteltavan kaiuttimen taajuusvasteen sekä tehovasteen tasaisuutta, Genelec on kehittänyt innovatiivisen Minimum Diffraction Enclosure (MDE™) -kaiutinkotelon, jossa on kaarevat sivut sekä pyöristetyt kulmat. Poikkeuksellisen tasaisen taajuusvasteen lisäksi kotelorakenteella saavutetaan erinomaiset äänikuvaominaisuudet.
Kompaktin ja tyylikkään ulkoasun saavuttamiseksi kotelon materiaaliksi on valittu painevalettu alumiini, joka mahdollistaa kotelon kokoon suhteutettuna suuren sisätilavuuden bassoelementin herkkyyden maksimoimiseksi. Alumiini on kevyttä, jäykkää ja hyvin vaimentavaa, joten se on erinomainen materiaali ohutseinäisen ja akustisesti "kuolleen" kotelon valmistamiseen. Alumiinikotelo suojaa tehokkaasti elektromagneettiselta säteilyltä ja se toimii myös vahvistimien jäähdytyselementtinä. Kotelo valetaan kahtena kappaleena, jolloin se pystytään avaamaan helposti esimerkiksi huoltoa varten.
Directivity Control Waveguide (DCW™) -suuntain integroidaan MDE™-koteloon hallitun suuntaavuuden saavuttamiseksi. Vakiosuuntaavuuden alarajataajuus määräytyy suuntaimen koon perusteella, jolloin suuremmalla suuntainpinta-alalla saavutetaan hallitumpi suuntaavuuskäyttäytyminen. Hallittu sivukenttäsäteily mahdollistaa suuren käyttökelpoisen kuuntelualueen, mikä on erittäin tärkeää monikanavaisessa äänentarkkailussa. Hallittu suuntaavuus vähentää myös rajapintaheijasteiden merkitystä, jolloin monitorointijärjestelmä toimii johdonmukaisesti erilaisissa akustisissa ympäristöissä.
Elementtikohtaisesti optimoidut tehovahvistimet.
Elektroniset jakosuotimet jakavat audiosignaalin taajuuskaistan osiin, jotka voidaan ohjata erillisiin vahvistimiin. Vahvistimet on liitetty kyseiselle taajuuskaistalle optimoituihin muuntimiin.
Tyypillisessä kaksitiekaiuttimessa aktiivinen jakosuodin tarvitsee kaksi vahvistinta: yhden bassoelementille ja toisen diskanttielementille. Vahvistimet liitetään suoraan aktiivikaiuttimien elementteihin, jolloin vahvistimien kuormitus on tunnettu ja yksinkertaisempi. Jokaisella elementtikohtaisella vahvistimella on vain rajallinen taajuusalue, jota se vahvistaa (vahvistin sijoitetaan aktiivisen jakosuotimen taakse), mikä yksinkertaistaa rakennetta.
Aktiivisella rakenteella on useita etuja:
- Vahvistimet liitetään suoraan kaiutinelementteihin, mikä tehostaa vahvistimien elementin äänikäämin vaimennuksen hallintaa ja vähentää dynaamisten muutosten esiintymistä elementin sähköominaisuuksissa. Se saattaa parantaa järjestelmän siirtymävastetta.
- Vahvistimen lähtövaatimukset ovat pienemmät. Kun energiaa ei mene hukkaan passiivisen jakosuotimen komponenteissa, vahvistimen tehovaatimukset ovat huomattavasti pienemmät (jopa puolta pienemmät joissakin tapauksissa) ilman, että kaiuttimen akustinen teho heikkenee. Tämä saattaa pienentää kustannuksia ja parantaa äänenlaatua ja järjestelmän luotettavuutta.
- Kun vahvistimen ja elementin välissä ei tapahdu hävikkiä, saavutetaan äärimmäinen akustinen tehokkuus.
- Aktiivinen teknologia pystyy tuottamaan ylivoimaisen äänentoiston suhteessa kokoon ja matalaan alarajataajuuteen.
- Kaikki kaiuttimet toimitetaan tehtaalla sovitettuina järjestelminä (vahvistimet, jakosuotimet ja kotelo-elementtijärjestelmät).
Yliohjauksen suojapiiri takaa turvallisen käytön ja elementtien pitkäikäisyyden.
Kriittisissä audiotuotantoympäristöissä on ratkaisevaa, että monitorointijärjestelmä on luotettava ja aina käytettävissä. Yksi tärkeimmistä syistä Genelecin menestykseen lähetystarkkaamokäytössä on tuotteidemme luotettavuus. Luotettavuuden takeena on sisäinen suojapiiri, joka on ollut kaikissa tuotteissa vuodesta 1978 lähtien.
Suojapiiri ehkäisee elementtien vikatiloja havaitsemalla signaalitasoja. Mikäli signaalissa esiintyy yhtäkkisiä piikkejä tai jatkuvia liian korkeita tasoja, suojapiiri laskee signaalin tasoa automaattisesti. Suojapiirin toiminta ei luonnollisestikaan vaikuta äänenlaatuun millään tavalla työskenneltäessä kaiuttimen määritellyissä käyttöolosuhteissa. Se vain ehkäisee signaaleja rikkomasta kaiutinta.
Suojapiirin ominaisuudet ja edut:
- Laskee signaalin tasoa tarvittaessa (esimerkiksi kun elementin äänikäämin lämpötila saavuttaa turvarajan), mikä parantaa kaiuttimen luotettavuutta merkittävästi.
- Jokaisen kaiuttimen ja alabassokaiuttimen sopiva suojapiirirakenne sallii järjestelmän äänitason maksimoimisen.
Edistynyt refleksiputken muotoilu parantaa bassotoiston ulottuvuutta.
Genelec käytti bassorefleksirakennetta jo ensimmäisessä tarkkailukaiuttimessaan S30:ssa vuonna 1978. Genelec on siitä lähtien tutkinut ja kehittänyt refleksiputken suorituskykyä sekä tehokkuutta. Kehitystyön tavoite on ollut parantaa bassotoiston ulottuvuutta ja äänenpainekapasiteettia erinomaisen matalien taajuuksien artikulaation ja tarkkuuden tuottamiseksi.
Sekä bassoelementti että refleksiaukko vaikuttavat refleksikotelon kokonaissäteilyyn. Suurin osa säteilystä on lähtöisin elementistä, mutta refleksikotelon resonanssitaajuudella elementin liikepoikkeaman amplitudi on pieni, jolloin suurin osa säteilystä tulee aukosta.
Virtausnopeuden minimoimiseksi putken poikkipinta-alan täytyy olla suuri. Kaiutinkotelon koko rajoittaa usein refleksiputken pituutta.
Pitkä kaareva refleksiputki maksimoi ilmavirtauksen, jotta kaiutin pystyy tuottamaan syvän bassotoiston ilman kompressiota. Putki päättyy leveään pyöreäreunaiseen aukkoon, joka sijaitsee kotelon takana minimoiden putken virtausääniä ja tuottaen erinomaisen bassoartikulaation.
Putken kaareva muoto on tarkoin suunniteltu ja se vähentää virtausääniä, kompressiota ja säröä. Putken sisäpään muotoilu minimoi suorille refleksiputkille tyypillisiä yskähdysääniä ja turbulenssia.
Huolellisesti suunniteltu refleksiputken rakenne vähentää bassoelementin liikepoikkeamaa ja parantaa matalien taajuuksien toiston lineaarisuutta sekä äänenpainekapasiteettia.
Monipuoliset kiinnitysvaihtoehdot soveltuvat useimpiin asennusratkaisuihin.
Genelecin kaiuttimissa on monipuoliset ripustusmahdollisuudet, jotka tekevät asennuksesta helppoa kaikissa kohteissa. Oikein sijoitetut kaiuttimet käyttäytyvät ihanteellisesti erilaisissa käyttöympäristöissä.
Laaja lisävarustevalikoimamme ja painevalettujen alumiinikoteloiden takalevyihin integroidut kiinteät M6-kiinnityspisteet tarjoavat ratkaisun useimpiin asennustilanteisiin. Pienissä kaiutinmalleissa kotelon pohjassa on 3/8-tuuman kierreinsertti, jota käyttäen kaiutin voidaan asentaa tukevaan mikrofonitelineeseen tai jalustaan. Suuremmissa ja painavammissa malleissa on M10-kiinnityspisteet. Lattiatelineisiin on saatavilla myös mallikohtaiset Iso-Pod jalusta-adapterit, joiden avulla saavutetaan kattavat säätömahdollisuudet sekä hyvä mekaaninen eristys kaiuttimen ja jalustan välille.
Näiden ominaisuuksien ansiosta tuotteitamme käytetään nykypäivänä ammattikäyttökohteiden lisäksi sekä julkistiloissa että kotikohteissa kaikkialla maailmassa.

Etsi jälleenmyyjäsi
1 x 4430A Smart IP kaiutin
1 x seinäkiinnike
1 x ruuvisetti
1 x 3-napainen ruuviterminaali
4430A Smart IP Asennuskaiutin
Awards
Dokumentit
Dokumentit
4430A Operating Manual 4430A Quick Setup Guide Smart IP for AV Brochure Special Colour Options Smart IP FAQ Case Study G Livelab TampereTiedostot
4430A Line Drawings (pdf) 4430A Line Drawings (dwg) 4430A - Simulation File (GLL) 4430A - Simulation File (EASE 4) 4430A - Simulation File (CLF) NOTE: Simulation File Use for 4430AUKK
Genelec Smart IP is a revolutionary loudspeaker family for installed audio applications, supporting single cable connectivity via standard Ethernet networking protocols. Smart IP loudspeakers receive power and audio, plus monitoring and management signalling over a single Ethernet cable. Smart IP does not introduce any performance compromises in terms of maximum sound pressure level or acoustic quality. It provides complete professional quality room compensation and multi-loudspeaker system alignment tools built into all loudspeakers, and allows several complete setups to be stored within the loudspeaker’s internal memory. Smart IP also enables easy integration into house automation systems by offering a public API command set.
• Single-cable connectivity using PoE+ without performance sacrifice.
• High maximum SPL on PoE+ power.
• Renowned Genelec audio and build quality.
• Support for open audio and IP standards.
• Uncompromising uncompressed low-latency audio streaming directly into each loudspeaker.
• Loudspeaker synchronisation to sub-microsecond level for solid acoustic imaging.
• Full set of acoustic room compensation and alignment tools built into each loudspeaker.
• Extensive accessory support.
• Complete public API command set.
• Designed and manufactured in Finland for high reliability, long lifetime and respecting environmental sustainability.
Almost any project, since the number of Smart IP loudspeakers in one installation is virtually unlimited, and IP networks themselves can support a very high loudspeaker count. This, with the very flexible audio streaming options available, enables complex installations with many speakers to be implemented quickly and easily.
